EMERSON DELTAV Analog Ountputs VE4033S2B1 KJ3221X1-BA1 Power Supply Redundant Module

Large Image : EMERSON DELTAV Analog Ountputs VE4033S2B1 KJ3221X1-BA1 Power Supply Redundant Module Get Best Price

Product Details:

Place of Origin:	JAPAN
Brand Name:	Emerson
Certification:	CE
Model Number:	VE4033S2B1 KJ3221X1-BA1

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Contact
Packaging Details:	New and original
Delivery Time:	3-5days
Payment Terms:	T/T/Palpal
Supply Ability:	1000

Contact Now

Detailed Product Description

Manufacturer:	Emerson	Power Supply Voltage:	VE4033S2B1 KJ3221X1-BA1
Voltage Type:	1-Phase	Rated Output Power:	200W / 0.2kW
Operational Temperature:	0 To 55 °C
Highlight:	Power Supply Analog Ountputs , Redundant Module Analog Ountputs , VE4033S2B1 Analog Ountputs

EMERSON DELTAV Analog Ountputs VE4033S2B1 KJ3221X1-BA1 Power Supply Redundant Module

Details:

Reduced system footprint:

The DeltaV system’s state-of-the-art form factor design of the I/O components enables you to mount the I/O interface carrier in a junction box in the field so you significantly reduce the footprint of your equipment and increase valuable control room space for other uses.

Environmental Specifications

Ambient Temperature	-40 to 70℃
Shock	10g ½ Sinewave for 11 msec
Vibration	1mm Peak to Peak from 5 to 16Hz; 0.5g from 16 to 150Hz
Airborne Contaminants	ISA-S71.04–1985 Airborne Contaminants Class G3
Relative Humidity	5 to 95% Non-Condensing IP 20 Rating
Terminal block key position	D4

Full system modularity:

The Traditional I/O subsystem was designed with your investment in mind. All components are

fully modular and may be installable under power. You add I/O interface carriers and I/O interfaces in groups of 4, 8, 16, or 32 channels as you need them. The modular design enables you to purchase the exact amount of I/O cards, 8-wide carriers, power/controllers, and 2-wide carriers you need and add more DeltaV I/O as your system grows.

Installation:

Save on wiring expenses by installing Classic Instrumentation in the field, near the actual field devices.

Mounting the controller with the I/O further reduces your wiring expenditures by eliminating the need for long runs of multi-cores. The integrated design of the Traditional I/O subsystem can eliminate the need for marshaling panels. This saves you even more in your total capital costs. The provision of in-line fuses and bussed power saves on installation costs compared with external fuses and power distribution.

Product Description

I.The Traditional I/O subsystem includes:

II.I/O interface carrier (a DIN rail surface mounted) on which all I/O related components are installed.

III.Bulk AC to 24 VDC power supply for field devices.

IV.An I/O interface consisting of an I/O card and an I/O terminal block.

V.A variety of analog and discrete I/O cards enclosed in a common form factor that easily plugs into the I/O interface carrier.

VI.A variety of I/O terminal blocks mounted on the I/O interface carrier that can be pre-wired before I/O card installation.

DeltaV Redundant Power Supply Module Models:

KJ3007X1-BA1 12P2062X072VE4014	PROFIBUS DP CARD
KJ3007X1-EA1 12P2413X032	PROFIBUS DP Terminal Block
KJ3002X1-BE1 12P0682X042 VE4005S2B2	Analog Output 8-Channel 4-20mA HART Card
KJ3002X1-BG1 VE4003S5B1 12P1731X012	Thermocouple mV CARD
KJ3001X1-CB1 VE4002S1T2B5 12P1985X032	DO 32-Channel 24 VDC High-Side Card
KJ3002X1-BA1 VE4003S2 12P0680X122	Analog Input 8 Channel 4-20mA HART Card
KJ3001X1-BH1 VE4002S2T1 12P0558X152	DO 8-Ch 120/230 VAC Isolated
KJ3001X1-BJ1 VE4002S1T2B2 12P0555X122	DO 8-Channel 24 VDC High Side Card
KJ1501X1-BC1 VE5008 12P2186X012	System Dual DC Power Supply (DC/DC)
KJ1501X1-BA2 VE5001 12P0677X062	AC/DC System Power Supply
KJ3001X1-BH1 VE4002S2T1 12P0558X152	DO 8-Ch 120/230 VAC Isolated
KJ3001X1-BD1 VE4001S3T2B2 12P0552X122	Discrete Input 120VAC DRY CONTACT
KJ3001X1-BG1 VE4002S1T1 12P0557X152	DO 8-Channel 24 VDC Isolated Card
KJ4002X1-BB1 VE4055S2C0 12P1728X042	Right 8 Wide Vertical Carrier
KJ4002X1-BC2	4 WIDE VERTICAL CARRIER TOP
KJ4002X1-BE1 12P4048X012	Top Extender Cable
KJ4002X1-BF2 12P3866X012	Bottom Extender Cable
KJ4003X1-BE1 12P3839X022	Vertical Left Side Extender
KJ4003X1-BF1 12P3839X022	Vertical Left Side Extender
KJ4005X1-BA1 SE3051C0 12P4683	POWER/CONTROLLER CARRIER
KJ4010X1-BF1 12P0831X042	Local Bus Left Extension
KJ4010X1-BG1 12P0830X042	Local Bus Right Extension
KJ4101X1-BA1 12P1870X012	IS 8 Wide Carrier
KJ4101X1-BB1 12P1871	IS LOCAL BUS ISOLATOR CARRIER
KJ4101X1-BC1 12P1872X012	IS Power Supply Carrier
KJ4110X1-CA1 12P1873X012	IS Extender Right-hand CARRIER
KJ4110X1-CB1 12P1874X012	IS Extender Right-hand CARRIER
KL2101X1-BA1 12P4987X062	Charm I/O CARD
KL3002X1-BA1 12P4627X052	DO 24 VDC High-Side
KL3003X1-BA1 12P4632X082	DI 24 VDC Dry Contact
KL3021X1-BA1 12P4628X062	AI 4-20 mA HART
KL3022X1-BA1 12P4629X042	AO 4-20 mA HART
KL4101X1-BA1 12P4989	CHARM I/O CARRIER
KL4201X1-BA1 SE4601T07 12P4986X052	Charm Base plate
KL4502X1-BA1 12P4990X042	Charm Terminal
KJ4001X1-GG1 12P1812X022	Thermocouple Terminal Block
KJ4001X1-HB1 12P0830X072	Local Bus Right Extender
KJ4002X1-BA1 VE4055S1C0 12P1727X042	Left 8 Wide Vertical Carrier
KJ4001X1-CC1 12P0733X032	4 Wire TX Terminal Block
KJ1501X1-BK1 SE5009 12P4685	System Power Supply 24 DC/DC
KJ1700X1-BA1 VE6006 12P1710X012	Media Converter
KJ1710X1-BA1 VE6019 12P3305X	Single Port Fiber Switch
KJ3001X1-BK1 VE4002S2T2 12P0556X142	DO 8-Channel 120/230 VAC High Side
KJ3001X1-CA1 VE4001S2T2B4 12P1980X042	DI 32-Channel 24 VDC Dry Contact Card
KJ3002X1-BB1 12P0683X072	ANALOG OUTPUT 4-20mA
KJ3002X1-BC1 VE4003S1B2 12P0681X072	Analog Input Module Final Assy 4-20mA Card
KJ3003X1-BA1 12P0914	SERIAL INTERFACE CARD
KJ3003X1-EA1 12P0921X032	Interface Terminal Block
KJ3009X1-BA1 VE4016 12P2514X052	Device Net CARD
KJ3101X1-BA1 12P1865X032	IS Discrete Output 560 mA MAX
KJ3102X1-BE1 12P2703	IS Analog Output 4-20mA with HART
